GPU Engine
GPU Architecture：NVIDIA Turing? TU106
Floating Point Performance：5.3 TFLOPS SP Peak
Memory
Memory Interface Width:：92-bit
Memory Bandwidth：336 GB/sec
Feature Support
Operation System
Windows 10 64-bit
Linux 64-bit
VITA Standards
VITA Standards
VITA 46.0 VPX Base Standard
VITA 46.4 PCI Express on VPX Fabric Connector
VITA 65 OpenVPX Architecture Framework for VPX
Display Support
Max. Displays per Board：4
Max. Digital Resoultion：7680x4320
Display Interface：Four DisplayPort 1.4 outputs to VPX P2
Power
Mechanical & Environment
Form Factor：Conduction cooled 3U VPX
Dimensions (mm)：100 x 160 mm
Operation Temperature (Standard)：0 to +55°C
Operation Humidity：Relative Humidity 5 to 90%
Operation Temperature (Optional)：-40 to +71°C (at wedge lock)
Storage Temperature：-40 to +125°C, Relative Humidity 5 to 95%
